Multi-function Board

ABM^? Multi-function Board (MB series) has a wide range of density and thickness,are widely used in building insulation. The product is mainly applied in partitions, metal/stone cladding curtain walls, light steel roofs, wall frames, ceilings, fire doors and floors to conserve energy,control sound,and provide fire protection.

Standard Specification

Product Properties

Product Application

Authenticity Verification

Product Type	MB 40	MB 50	MB 60	MB 80	MB 100	MB 120
Nominal Density, kg/m³	40	50	60	80	100	120
Thickness, mm	50~150	40~150	40~250	25~250	25~200	25~150
Size(L×W), mm	1200 x 600

Properties	MB 40	MB 50	MB60	MB 80	MB100	MB120	Unit	Test Method
Thermal Conductivity(25℃)	≤0. 037						W/(m ?K)	GB/T 10295
Reaction to Fire	A1						---	GB 8624
Melting Temperature	≥1000						℃	----
Surface Burning Characteristics	Smoke Development≤5, Flame Spread=0						---	ASTM E84
Acidity Coefficient	≥1.6						---	GB/T 5480
Water Repellence	≥99						％	GB/T 10299
Mass Moisture Absorption	≤0.5						％	GB/T 5480
Short-term Water Absorption (partial immersion, 24h)	≤0.2						kg/m2	GB/T 30805
Dimensional Stability	≤0.5						％	GB/T 30806
Corrosiveness	Corrosion Free						---	ASTM C665
Formaldehyde Emission	≤0.5						mg/(kg?h)	GB/T 32379
Noise Reduction Coefficient（NRC）	≥0.80						---	GB/T 18696

Thermal Insulation System for Light Steel Structure

1.Gypsum Board

2.Light Steel Frame

3.ABM Multi-function Board (MB series)

4.Fiber Cement Board

5.ABM Multi-function Board (MB series)

6.Facing

7.Stud

8.Cladding

Thermal Insulation System for Curtain Wall

1.Substrate

2.Embedded Parts

3.Vertical Keel

4.Horizontal Keel

5.Anchor

6.ABM External Thermal Insulation Board (FRB series)

7.Stone Cladding

Thermal Insulation System for Curtain Wall

1.Substrate

2.Steel Frame

3.ABM Multi-function Board (MB series)

4.Facing

5.Anchor

6.Metal Pane

Thermal Insulation System for Sandwich Wall

1.Gypsum Board

2.Frame

3.ABM Multi-function Board (MB series)

4.Gypsum Board

5.Finishing Coat

Thermal Insulation System for Partition Wall

1.Gypsum Board

2.Frame

3.ABM Multi-function Board (MB series)

4.Gypsum Board

5.Finishing Coat

Thermal Insulation System for Attic

1.Interior Decorative Board

2.Waterproof and Vapor Permeable Membrane

3.ABM Multi-function Board (MB series)

4.Stud

5.Fiber Cement

6.Hanging Tile

7.Roof Tile
