Industrial Board

ABM^? Industrial insulation rock wool board has good thermal stability, chemical stability and mechanical properties. At the same time, it also has excellent sound absorption and thermal insulation performance. The non-combustion performance can reach class A1. Low-chlorine products can be produced according to customer requirements, and can be laminated with aluminum glass cloth, aluminum foil, glass fiber cloth and other veneer materials according to different applications.

Standard Specification

Product Properties

Product Application

Authenticity Verification

Product Type	IB60	IB80	IB100	IB120	IB150
Nominal Density, kg/m³	60	80	100	120	150
Thickness, mm	40~150	25~250	25~250	25~200	25~150
Size (length x width), mm	1200x600

Product Properties		IB60	IB80	IB100	IB120	IB150	Unit	Standard
Thermal Conductivity	50℃	≤0.040	≤0.038	≤0.038	≤0.038	≤0.038	W/(m?K)	GB/T 10295 ASTM C518 ASTM C177
	100℃	≤0.046	≤0.045	≤0.043	≤0.043	≤0.043
	150℃	≤0.060	≤0.055	≤0.050	≤0.050	≤0.050
	200℃	≤0.077	≤0.065	≤0.058	≤0.060	≤0.060
	250℃	≤0.095	≤0.075	≤0.063	≤0.063	≤0.063
	300℃	≤0.120	≤0.090	≤0.070	≤0.072	≤0.072
Max Service Temperature		500	650	650	650	650	℃	ASTM C411
Max Service Temperature		Surface material: 80					℃	ASTM C411
Linear Shrinkage		≤2	≤2	≤2	≤2	≤2	%	ASTM C356
Water Vapor Sorption		≤2.0%	≤2.0%	≤2.0%	≤2.0%	≤2.0%	%	ASTM C1104
Water Repellent		≥99	≥99	≥99	≥99	≥99	%	GB/T 10299
Water Leachable Chloride Content*		≤10	≤10	≤10	≤10	≤10	PPM	ASTM C871
Reaction to Fire		Class A1 Noncombustible, Smoke Development=5, Flame Spread=0					--	GB 8624 ASTM E84
Environment		Asbestos free, no CFCs, HCFCs, HFCs					--	--
Corrosiveness		Corrosion Free					--	ASTM C665

*Refer to low water leachable chloride content products used for austenitic stainless steel, meet ASTM C795's requirements;

Other properties meet GB/T 11835 or ASTM C612's requirements.

ABM^? industrial boards are widely used on industry furnace, boilers, oven, big diameter pipelines, storage tanks and equipments for thermal, fireproof, acoustic insulation.
